EV40DR Dual EV Charger
Product Details
Brand: Sun Country Highway
UPC: 672546099413
Amperage: 40 Amp
Installation Type: Hardwired
Networking: Non-Networked
Warranty: 3-Years
EV40DR EV Charger
Charge two vehicles with one station.
The EV40DR is a 32 Amp, Level 2 hardwired station that can charge two electric vehicles with one station on one shared circuit. The EV40D splits electricity between two vehicles, with up to 16 Amps of electricity each when both are charging and up to 32 Amps when one vehicle is charging. It is installed on one 40 Amp circuit. The EV40DR can be mounted on a wall or on one of our free-standing pedestal options. The EV40D is a universal charging station and will charge any electric vehicle. The ruggedized charger is constructed with a rubber over-molded SAE J1772 connector and a five-year warranty. Available with 18ft or 25ft cable.
Features of the EV40DR Dual Charging Station include:
- 7.7kW of power to charge two electric vehicles quickly
- Fully sealed NEMA 4 station enclosure for indoor or outdoor installation
- Two 25 foot charging cables for installation flexibility and superior vehicle reach
- Two SAE J1772 universal connectors
- Two wall or pedestal mount SAE J1772 connector holsters
- Operating temperatures: -30°C to 50°C (-22°F to 122°F)
- 5-year warranty
- ETL Safety Certified
- ENERGY STAR® certified
| General | |
| Charging Power | 32 Amp (7.7kW max) |
| Product Dimensions | 19.7"L x 8.9"W x 5.3"D |
| Product Weight | 21 lbs |
| Installation | Hardwired (3 foot service whip provided) |
| Supply Circuit | 208/240V, 40A |
| Warranty | 5 years |
| Charge Cable Length | 25 feet for each cable (2 cables total) |
| Vehicle Connector Type | Lockable SAE J1772 (2) |
| Accessories Included | 2 - SAE J1772 Connector Holsters (wall or pedestal mount); 2 - Connector Locks and Keys |
| Enclosure | Fully Sealed NEMA 4 |
| Environment Rating | Indoor / Outdoor |
| Operating Temperature | -22°F to 122°F (-30°C to +50°C) |
| Certifications | ETL, cETL, ENERGY STAR® |
